o XYZCAM engineering designed structure D; an internally-reinforced frame providing the best dynamic rigidity and stability during rapid feeding and heavy cutting
o 408(1325) 1300x2540mm / 4´2"x 8´4"/ 50"x100"
o 510(1530) 1524x3048mm / 5´x 10´/ 60"x120"
o 710(2030) 2100x3048mm / 6´8" x 10´/ 82"x120"
o 714(2040) 2100x4064mm / 6´8" x 13´4〞/ 82"x160"
o Customize working envelope 6mets, 8mts up to 12mts long
o Z-axis travel 304 mm, optional up to 800 mm
o Helical rack and pinion drive system on X and Y axis
o Low-backlash planetary gear boxes
o Precision ball screw on Z axis
o Brushless digital A/C servo drives and motors on all axis, vertical servo motor assembly long axis for more space saving
o Maximum axis speed 100 m/min (1,600 mm/s) depending on controller, motors and drives
o Maximum versatility, optional multi-purpose
